18
GB0007003 HOPE
Imperial College London
Prototype
P
Internal Combustion Engine
ICE
Gasoline
Technical Inspections
Before they get on track, Prototype vehicles need to pass a series of 10 technical inspections. For some, the only goal is getting through this test. Many never even make it that far.
4/10
In progress
In progress
Passed
1. Inspection Queue Entrance
4 / 4
SHELL logo front, Race number, Partner sticker / both sides
(4 a-c)
Lift here arrow stickers
(26 f)
Opening mechanism stickers
(30 c)
Other stickers < 400 cm²
(4 d)
Passed
2. Driver Checks
25 / 25
Appropriate motorsports helmet - Primary Driver
(21 a-g)
Three-quarter helmet - Primary Driver
(21 b)
Helmet label readable - Primary Driver
(21 c)
Helmet has no cracks/indentations - Primary Driver
(21 c)
Visor is clear and has no cracks - Primary Driver
(21 d)
Single piece fire retardant racing suit (s) - Primary Driver
(22 a)
Fire retardant gloves - Primary Driver
(22 c)
Flat, closed toe shoes - Primary Driver
(22 b)
Cotton socks, no bare skin visible - Primary Driver
(22 b, e)
FCR balaclava if used - Primary Driver
(22 d)
Driver weight (> 50kg) - Primary Driver
(20 a)
Appropriate motorsports helmet - Reserve Driver
(21 a-g)
Three-quarter helmet - Reserve Driver
(21 b)
Helmet label readable - Reserve Driver
(21 c)
Helmet has no cracks/indentations - Reserve Driver
(21 c)
Visor is clear and has no cracks - Reserve Driver
(21 d)
Single piece fire retardant racing suit (s) - Reserve Driver
(22 a)
Fire retardant gloves - Reserve Driver
(22 c)
Flat, closed toe shoes - Reserve Driver
(22 b)
Cotton socks, no bare skin visible - Reserve Driver
(22 b, e)
FCR balaclava if used - Reserve Driver
(22 d)
Driver weight (> 50kg) - Reserve Driver
(20 a)
Ballast required?
(20 b)
Ballast based on lightest driver
(20 b)
Ballast of suitable type, proper location, sealed
(20 b)
Must pass again
3. Brakes
8 / 10
Brake documentation
(67 c ii)
2 independently operated Hydraulic brake system 1 front & 1 rear
(43 a)
Foot operated front brake by single pedal
(43 a)
Rear brake by single lever or pedal
(43 a)
Brake pedal 1,000 mm², min width 30 mm
(43 a v)
Brake rotors point in direction of wheel rotation
(43 a)
No acting on tyres
(43 a)
All wheels have brakes
(43 a)
Ergonomy
(43 a)
Effectiveness Ramp Test - Dynamic
(43 b)
Must pass again
4. Driver Safety
20 / 26
The safety harness is designed for motorsport activities.
(29 g)
Mounting points are clearly accessible for inspection
(29 e)
Safety Belts = 5 mounting points
(29 a)
Must have minimum 5 independent belts attached to structure - chassis fixing
(29 a)
Crotch strap under body
(29 b)
Safety belt must be in straight line between mounting point and shoulder
(29 f)
Safety belt has a tight fit (no slack), length adjustor high enough for adjustment
(29 c)
No modifications of safety belt
(29 h)
Safety belt strength verified
(29 d)
Internal/ext'l opening mech effective/intuitive
(30 c)
Method of opening accurately marked with sticker
(30 c)
No adhesive tape to close driver compartment from outside
(30 d)
Roll bar resist 70 kg all directions
(26 d)
Roll bar 50 mm > driver's head - Primary Driver
(26 b)
Roll bar width > shoulders - Primary Driver
(26 c)
Roll bar 50 mm > driver's head - Reserve Driver
(26 b)
Roll bar width > shoulders - Reserve Driver
(26 c)
Driver exit < 10 seconds - Primary Driver
(30 a)
Driver exit < 10 seconds - Reserve Driver
(30 a)
Front vis 180° & Tint - driver must be seen - Primary Driver
(28 a)
Rear visibility - see cheat sheet - Primary Driver
(28 b)
Front vis 180° & Tint - driver must be seen - Reserve Driver
(28 a)
Rear visibility - see cheat sheet - Reserve Driver
(28 b)
Quality of body driver collision protection
(26 a-d)
Front Crumple Zone = 100 mm
(25 a ii)
Crumple space-protect from front/side impact
(25 a) ii, 26 a)
Passed
5. Vehicle Dimensions
6 / 6
Height < 1000 mm
(39 a)
Width < 1300 mm
(39 e)
Length < 3500 mm
(39 f)
Track width > 500 mm
(39 b)
Wheelbase > 1000 mm
(39 d)
Maxi height 1.25 X track width
(39 c)
Must pass again
6. Mechanical Vehicle Design
18 / 20
Vehicle weight < 140 kg
(39 g)
Windows material (polycarbonate/Lexan)
(25 f)
Electrical automotive horn, sound level > 85 dBa @ 4 m
(31 a-c)
Fully closed body
(25 h, k)
Solid floor & frame
(25 j)
No external appendages or sharp edges
(25 c)
Body panels do not change shape in wind
(25 b, d)
Chain/belt guard (all rotating equipment)
(34 g)
Running wheels (Pr:3/4)
(25 a) i )
Rims compatible with the dimensions of the tyre
(41 a-b)
Wheel compliance
(41 a, 48 c)
Tyres are in good condition
(49 d)
Tyre valves are accessible
(49 f)
Bulkhead rigid & fire resistant
(27 b, d)
Bulkhead isolates energy/driver compartment
(27 a)
Wheels isolated from driver, chassis, or body
(41 c)
Nothing touching wheels (e.g. batt, wires, etc...)
(41 d)
Steering is efficient and has no play
(32 b)
If electric steering, demonstrate default safe state
(32 d)
Intuitive steering control
(32 b)
Not yet started
7. Electrical Design
0 / 18
Correct vehicle electrical schematic
(67 c)
Max 60 V Peak
(57 a)
Only one Battery, 2 terminals, single physical package
(57 b) ii)
Batt mount firm, behind b/head, not under seat
(57 c)
Main fuse < 300 mm from +ve terminal ADD fuse size
(57 e)
Main fuse is sized correctly for the system
(57 e)
Elec system has proper fuse protection
(57 g)
Drivers Display
(57 i)
Electrical enclosures - transparent
(57 j)
Electrical wiring connections visible/no splices
(57 k)
JM Installation in engine compartment
(56 b)
JM visible and accessible from outside
(56 b)
JM Correct circuit location
(56 c) i)
JM Counting Correctly
(56 c)
Internal Estop Switch
(37 g) i)
External Estop mounting location
(37 g) ii)
Latching External Estop push button (no push/pull levers)
(37 h)
Blue triangle sticker
(37 g) iii)
Must pass again
8. Energy Verification
4 / 35
1 Shell fuel tank 30/100/250 cc
(61 a)
Fuel tank vertical position
(61 b)
Fuel tank easy to refill (with burette)
(61 b)
Translucent and rigid hoses
(61 f)
Fuel lines are safely routed
No loops are present in fuel lines
Safety valve location (between reg and air tank)
(60 d) i)
No valve(s) after the flowmeter
Fuel pressure gauge visibile and easy to read
(60 c) iii)
LFM mounted in the vertical position
(62 i)
LFM securely mounted inside vehicle
(62 i)
LFM mounted below fuel injector and fuel tank
(62 i)
Fuel line from tank routed to LFM fuel inlet
(62 c)
Fuel filter installed on LFM inlet
(62 i)
Fuel injection only
(62 e)
No electrical fuel pump
(60 b)
Exhaust system evacuates outside
(35 a, b)
Exhaust Solid/no fatigue/leak, OK for high temp
(35 c, d)
4 stroke engine
(59)
Air intake free of obstruction/ foreign objects
(62 f)
No blow-by gas recycling, is collected in container
(62 f)
If engine temp regulated, must be pressurized, pure water only
(60 f)
Cooling system designed safely
(60 f)
No auxiliary energy sources
(60 e)
Fuel line internal diameter
Air removal completed and validated
No leaks in fuel line
Safety valve tested at 5 bars Max (ALL inspectors MUST wear goggles!!)
(60 c) iv)
Electric starter only
(64 a)
Emergency shutdown function - correct design
(37)
Efficiency of emergency shutdown
(37 a-c)
Efficency of Dead man's switch
(37 i)
Starter cannot propel vehicle
(64 b)
Clutch effective
(34)
Check LFM is reading (computer)
Passed
9. Telemetry
2 / 2
Joulemeter issued to team?
Liquid Flowmeter issued to team?
Not yet started
10. Final Checks
0 / 4
Technical Sticker received
Safety Sticker received
Pit Crew vests received
Transponder received
