Shell Eco-marathon Poland 2026 | Avispado | Instituto de Educación Secundaria Leonardo Da Vinci

Poland 2026

Offline mode, showing a cached version.

712

ES0013002 Avispado

Instituto de Educación Secundaria Leonardo Da Vinci

Results

Attempt 4

77.5

48.2

km/kWh

mi/kWh

BEST RESULT

1 2 3 4 5

Current Rank

14th / 18

13 87.0 km/kWh 54.0 mi/kWh +12.2%

14 77.5 km/kWh 48.1 mi/kWh

15 73.1 km/kWh 45.4 mi/kWh -5.7%

Technical Inspections

Before they get on track, Urban Concept vehicles need to pass a series of 10 technical inspections. For some, the only goal is getting through this test. Many never even make it that far.

10/10
Complete 10/10 inspections passed

Passed

1. Inspection Queue Entrance

4 / 4

Passed

2. Driver Checks

13 / 13

Appropriate motorsports helmet - Primary Driver (21 a-g)

Helmet label readable - Primary Driver (21 c)

Helmet has no cracks/indentations - Primary Driver (21 c)

Visor is clear and has no cracks - Primary Driver (21 d)

Single piece fire retardant racing suit (s) - Primary Driver (22 a)

Fire retardant gloves - Primary Driver (22 c)

Flat, closed toe shoes - Primary Driver (22 b)

Cotton socks, no bare skin visible - Primary Driver (22 b, e)

FCR balaclava if used - Primary Driver (22 d)

Driver weight (> 70kg) - Primary Driver (20 a)

Ballast required? (20 b)

Ballast based on lightest driver (20 b)

Ballast of suitable type, proper location, sealed (20 b)

Passed

3. Brakes

10 / 10

Brake documentation (67 c ii)

Brake rotors point in direction of wheel rotation (43 a)

Ergonomy (both hands on steering mech.) (32 c)

Effectiveness Ramp Test - Dynamic (51 e)

4 disc hydraulic brake (51 a)

X design or front / rear. One dual master cylinder or 2 master cyls (51 b)

Single brake pedal with at least 2,500 mm² (51 a)

Parking brake must keep vehicle stationary (51 d)

Disc thickness > 3 mm (51 a)

Commercial brake system, not bicycle (51 a)

Passed

4. Driver Safety

21 / 21

The safety harness is designed for motorsport activities. (29 g)

Mounting points are clearly accessible for inspection (29 e)

Safety Belts = 5 mounting points (29 a)

Must have minimum 5 independent belts attached to structure - chassis fixing (29 a)

Crotch strap under body (29 b)

Safety belt must be in straight line between mounting point and shoulder (29 f)

Safety belt has a tight fit (no slack), length adjustor high enough for adjustment (29 c)

No modifications of safety belt (29 h)

Safety belt strength verified (29 d)

Quality of body driver collision protection (26 a)

Internal/ext'l opening mech effective/intuitive (30 c)

Method of opening accurately marked with sticker (30 c)

No adhesive tape to close driver compartment from outside (30 d)

Roll bar resist 70 kg all directions (26 d)

Roll bar 50 mm > driver's head - Primary Driver (26 b)

Roll bar width > shoulders - Primary Driver (26 c)

Driver exit < 10 seconds - Primary Driver (30 a)

Front vis 180° & Tint - driver must be seen - Primary Driver (28 a)

Rear visibility - see cheat sheet - Primary Driver (28 b)

Quality of body driver collision protection (26 a-d)

Crumple space-protect from front/side impact (25 a) ii, 26 a)

Passed

5. Vehicle Dimensions

9 / 9

Height 1000 - 1300 mm (45 a)

Width 1200 - 1300 mm (45 b)

Length 2200 - 3500 mm (45 c)

Track width > 1000 mm (front) (45 d)

Track width > 800 mm (rear) (45 d)

Wheelbase > 1200 mm (45 e)

Ground clearance > 100mm (45 g)

Drivers compartment > 880 mm (45 f)

Width at drivers shoulder > 700 mm - Primary Driver (45 f)

Passed

6. Mechanical Vehicle Design

32 / 32

Passed

7. Electrical Design

22 / 22

Correct vehicle electrical schematic (67 c)

Charger built for battery (57 d) iii)

Charging Protection (fire blanket, Lipo bag) (24 j)

Capacity < 1000 Wh (57 d) iv)

Max 60 V Peak (57 a)

Only one Battery, 2 terminals, single physical package (57 b) ii)

Solid metal containment tray OR Lipo bag (57 d) vi)

Batt mount firm, behind b/head, not under seat (57 c)

Main fuse < 300 mm from +ve terminal ADD fuse size (57 e)

Main fuse is sized correctly for the system (57 e)

Elec system has proper fuse protection (57 g)

Drivers Display (57 i)

Electrical enclosures - transparent (57 j)

Electrical wiring connections visible/no splices (57 k)

JM Installation in engine compartment (56 b)

JM visible and accessible from outside (56 b)

JM Correct circuit location (56 c) i)

JM Counting Correctly (56 c)

Internal Estop Switch (37 g) i)

External Estop mounting location (37 g) ii)

Latching External Estop push button (no push/pull levers) (37 h)

Blue triangle sticker (37 g) iii)

Passed

8. Energy Verification

10 / 10

Documentation - Schematic (67 c)

Documentation - Battery/BMS (67 c)

Documentation - Motor controller (67 c)

Self-built battery - cell level current protection (57 d) ii)

In-vehicle Battery Management System (57 d) i)

Purpose built motor controller (66 a)

Estop Function - Physical Isolation of Batt (37 e)

Dead man's switch (37 i)

Efficiency of emergency shutdown (37)

Battery + and - isolated from frame and body (57 f)

Passed

9. Telemetry

1 / 8

Passed

10. Final Checks

4 / 4

Previous participation
Event	Vehicle category	Energy class	Rank	Result
Europe and Africa 2025	Urban Concept	Battery Electric	12	67.7km/kWh 42.07mi/kWh
Europe and Africa 2024	Urban Concept	Battery Electric	13	59.15km/kWh 36.75mi/kWh
Europe and Africa 2023	Urban Concept	Battery Electric	-	Passed technical inspection
