Shell Eco-marathon Brazil 2026 | EcoVolt CCM | Instituto Tecnológico y de Estudios Superiores de Monterrey Campus Ciudad de México

Brazil 2026

Offline mode, showing a cached version.

328

MX0002001 EcoVolt CCM

Instituto Tecnológico y de Estudios Superiores de Monterrey Campus Ciudad de México

Prototype P Battery-Electric BE

Technical Inspections

Before they get on track, Prototype vehicles need to pass a series of 10 technical inspections. For some, the only goal is getting through this test. Many never even make it that far.

9/10
In progress 9/10 inspections passed

Passed

1. Inspection Queue Entrance

5 / 5

Passed

2. Driver Checks

26 / 26

Passed

3. Brakes

10 / 10

Brake documentation (67 c ii)

2 independently operated Hydraulic brake system 1 front & 1 rear (43 a)

Foot operated front brake by single pedal (43 a)

Rear brake by single lever or pedal (43 a)

Brake pedal 1,000 mm², min width 30 mm (43 a v)

Brake rotors point in direction of wheel rotation (43 a)

No acting on tyres (43 a)

All wheels have brakes (43 a)

Ergonomy (43 a)

Effectiveness Ramp Test - Dynamic (43 b)

Passed

4. Driver Safety

26 / 26

Passed

5. Vehicle Dimensions

6 / 6

Must pass again

6. Mechanical Vehicle Design

19 / 20

Vehicle weight < 140 kg (39 g)

Windows material (polycarbonate/Lexan) (25 f)

Electrical automotive horn, sound level > 85 dBa @ 4 m (31 a-c)

Fully closed body (25 h, k)

Solid floor & frame (25 j)

No external appendages or sharp edges (25 c)

Body panels do not change shape in wind (25 b, d)

Chain/belt guard (all rotating equipment) (34 g)

Running wheels (Pr:3/4) (25 a) i )

Rims compatible with the dimensions of the tyre (41 a-b)

Wheel compliance (41 a, 48 c)

Tyres are in good condition (49 d)

Tyre valves are accessible (49 f)

Bulkhead rigid & fire resistant (27 b, d)

Bulkhead isolates energy/driver compartment (27 a)

Wheels isolated from driver, chassis, or body (41 c)

Nothing touching wheels (e.g. batt, wires, etc...) (41 d)

Steering is efficient and has no play (32 b)

If electric steering, demonstrate default safe state (32 d)

Intuitive steering control (32 b)

Passed

7. Electrical Design

22 / 22

Correct vehicle electrical schematic (67 c)

Charger built for battery (57 d) iii)

Charging Protection (fire blanket, Lipo bag) (24 j)

Capacity < 1000 Wh (57 d) iv)

Max 60 V Peak (57 a)

Only one Battery, 2 terminals, single physical package (57 b) ii)

Solid metal containment tray OR Lipo bag (57 d) vi)

Batt mount firm, behind b/head, not under seat (57 c)

Main fuse < 300 mm from +ve terminal, ck fuse size (57 e)

Main fuse is sized correctly for the system (57 e)

Elec system has proper fuse protection (57 g)

Drivers Display (57 i)

Electrical enclosures - transparent (57 j)

Electrical wiring connections visible/no splices (57 k)

JM Installation in engine compartment (56 b)

JM visible and accessible from outside (56 b)

JM Correct circuit location (56 c) i)

JM Counting Correctly (56 c)

Internal Estop Switch (37 g) i)

External Estop mounting location (37 g) ii)

Latching External Estop push button (no push/pull levers) (37 h)

Blue triangle sticker (37 g) iii)

Passed

8. Energy Verification

10 / 10

Documentation - Schematic (67 c)

Documentation - Battery/BMS (67 c)

Documentation - Motor controller (67 c)

Self-built battery - cell level current protection (57 d) ii)

In-vehicle Battery Management System (57 d) i)

Purpose built motor controller (66 a)

Estop Function - Physical Isolation of Batt (37 e)

Dead man's switch (37 i)

Efficiency of emergency shutdown (37)

Battery + and - isolated from frame and body (57 f)

Passed

9. Telemetry

1 / 1

Passed

10. Final Checks

4 / 4

Previous participation
Event	Vehicle category	Energy class	Rank	Result
United States 2026	Prototype P	Battery Electric Battery Electric	-	Passed technical inspection
Brazil 2025	Prototype P	Battery Electric Battery Electric	-	Passed technical inspection
Americas 2025	Prototype P	Battery Electric Battery Electric	-	Passed technical inspection
Americas 2024	Prototype P	Battery Electric Battery Electric	17	150.29km/kWh 93.39mi/kWh
Americas 2023	Prototype P	Battery Electric Battery Electric	-	Passed technical inspection
United States 2022	Prototype P	Battery Electric Battery Electric	-	Passed technical inspection
